69mm PET Oil & Wine Bottle Preform – Full Specifications & Customization
Detailed Product Description
Our 69mm PET bottle preforms are engineered to meet the demands of high-quality oil and wine packaging. Constructed from food-grade PET material, they offer exceptional clarity, durability, and chemical resistance. The precise 69mm outer diameter and 62mm inner diameter ensure compatibility with standard closures for a perfect, leak-proof seal. Ideal for large-volume containers (typically 3L to 5L+), these preforms are the reliable foundation for sturdy, premium bottles. Full customization of color and a complete range of neck finishes (27mm to 72mm) are available to match your specific brand and production requirements.
Enhanced Key Features & Benefits
Precision Engineering for Perfect Performance:
Consistent Dimensions: Manufactured with tight tolerances (±0.3mm), ensuring every preform fits seamlessly on blowing machines and with caps, reducing production downtime.
Superior Seal: The precisely molded neck and thread design guarantee an airtight and secure closure, preserving product freshness and preventing leakage during transport and storage.
Optimal Material Distribution: Designed for even stretching during the blow-molding process, resulting in finished bottles with consistent wall thickness, excellent clarity, and high burst pressure resistance.
Premium PET Material Properties:
Food-Safe & Compliant: Made from 100% virgin, food-grade PET resin. Compliant with international safety standards including FDA (US) and EU regulations for food contact materials.
High Clarity & Gloss: Offers brilliant transparency to showcase your product's color and purity, enhancing shelf appeal.
Lightweight & Strong: Provides an excellent strength-to-weight ratio, reducing shipping costs while ensuring durability.
Chemical Resistance: Inert to oils, alcohols, and most acids, ensuring the preform does not interact with or contaminate your product.
Complete Customization & Flexibility:
True Color Matching: We can match any Pantone color or sample you provide. Standard options include Clear, Light Blue, Green, and Amber (UV barrier for light-sensitive oils).
Comprehensive Size Range: Not just 69mm. We supply a full spectrum of neck finishes to support your entire product line, from small sampler sizes to large industrial containers.
Tailored Solutions: Our engineering team can work with you to adjust preform weight, length, and design to optimize performance for your specific bottle shape and blowing equipment.
Designed for Manufacturing Efficiency:
High Blow-Up Ratio: Engineered for stable processing, leading to high yields and lower per-bottle costs in your production.
Low Acetaldehyde (AA): For sensitive products like water and certain beverages, we offer low-AA material options upon request.
Clean Packaging: Preforms are packaged in clean, sealed bags or boxes to prevent dust contamination before use.
Detailed Specifications Table
| Neck Finish (mm) |
Typical Bottle Capacity |
Best For |
Key Advantage |
| 27mm |
50ml - 250ml |
Sample packs, premium miniatures, syrups |
Cost-effective for small, high-value products. |
| 32mm |
200ml - 500ml |
Craft spirits, luxury oils, condiments |
Elegant appearance for gift-ready packaging. |
| 36mm |
500ml - 1L |
Wine, spirits, mid-range edible oils |
The most common standard for 750ml wine bottles worldwide. |
| 46mm |
1L - 2L |
Juices, cooking oils, household liquids |
Excellent balance of pouring flow and closure cost. |
| 62mm |
2L - 3L |
Large juice formats, value-sized oils |
Stable base for larger, handle-style containers. |
| 69mm (Main Product) |
3L - 5L+ |
Bulk edible oil, wine in bag-in-box, industrial liquids |
Fast filling speeds, extremely robust seal for heavy containers. |
| 72mm |
5L - 10L+ |
Industrial oils, chemicals, water dispensers |
Maximum flow rate for efficient filling of very large containers. |
Technical Data for 69mm Preform:
Material: Food-Grade PET (Polyethylene Terephthalate)
Color: Customizable (Standard: Clear)
Neck Outer Diameter (O.D.): 69.0 mm ±0.3mm
Neck Inner Diameter (I.D.): 62.0 mm ±0.3mm
Preform Weight: Customizable based on final bottle weight (typical range: 65g - 120g for large bottles).
Barrier Options: Available with UV inhibitors or oxygen-scavenging technology for extended shelf life.
Extended Customization Service Workflow
Inquiry & Consultation: Share your bottle design, target capacity, product type, and desired color.
Technical Proposal: Our engineers recommend the optimal preform weight, neck finish, and PET resin type. A 3D model or drawing can be provided.
Sampling: We produce a small batch of preforms for your testing and approval. This step ensures compatibility with your blowing machine and final bottle quality.
Commercial Agreement: Finalize pricing, lead time, and payment terms upon sample approval.
Production & QC: Full-scale production begins with in-process quality checks for weight, dimensions, and visual defects.
Delivery & Support: Products are carefully packed and shipped. We provide ongoing technical support.
Quality Assurance & Certifications
We operate a fully integrated quality management system. Every batch of raw material is inspected, and preforms undergo rigorous testing, including:
Dimensional accuracy checks
Visual inspection for defects (black spots, haze, contamination)
Lab testing for intrinsic viscosity (IV) and color consistency
Available Certificates: Material Safety Data Sheets (MSDS), FDA Compliance Letter, ISO 9001:2015 Quality Management System certification.
Target Industries & Applications
Edible Oils: Sunflower oil, olive oil, coconut oil, blending oils.
Beverages: Wine, spirits, vinegar, juice concentrates.
Liquid Food: Syrups, liquid sweeteners, sauces.
Non-Food: Motor oil additives, detergents, agricultural chemicals, windshield washer fluid.
Why Choose Us?
Specialist Manufacturer: We focus solely on PET preforms, ensuring deep expertise and dedicated production lines.
One-Stop Solution: From standard sizes to fully custom projects, we simplify your supply chain.
Global Export Experience: Familiar with international logistics, documentation, and packaging standards for safe overseas delivery.
Competitive Pricing: Direct factory pricing without middleman markups, offering outstanding value.
Reliable Partner: We build long-term relationships based on consistent quality, on-time delivery, and responsive communication.
Ready to Start Your Project? Contact us today to discuss your needs, request free samples, and get a competitive quote. Let us help you create the perfect packaging for your product.
